Charnwood (N3FJ10) Bowl Reversing Jaws 10" Diameter for Nexus3 Chuck
Remount finished bowls securely with Charnwood N3FJ10 10-inch reversing jaws for Nexus3 chucks. Fits 45mm to 217mm bowls with 8 rubber-coated fixings.
- Express delivery express Mon to Fri, order before 14:00
- Click and collect
- 30 day returns
Secure checkout
Put the finishing touch on your woodturning projects with the Charnwood N3FJ10 Bowl Reversing Jaws, designed for the Nexus3 chuck and compatible alternative brands. Also known as Cole jaws or Flat jaws, this 10" Diameter attachment is essential for remounting completed bowls to refine the outside shape, or to clean up and remove unwanted spigots, recesses, and jaw marks. Built for versatility, they accommodate bowl diameters ranging from 45mm up to 217mm.
The system features 8 rubber-coated fixings to hold your workpiece securely in place, and the jaws adjust across 7 different positions in 12mm intervals to suit your exact dimensions. When mounted to a Charnwood Nexus3 chuck, the outer edge measures 210mm diameter when closed and 237mm diameter when opened, requiring a chuck with a minimum jaw travel of 24mm. Please note that a maximum rpm of 600 applies, and dimensions will vary when fitted to other compatible chucks depending on their jaw travel.
Features
- Bowl reversing jaws, also known as Cole jaws or Flat jaws, for remounting finished bowls to re-shape the outside or remove unwanted spigots, recesses or jaw marks
- Our N Type jaws are designed for use with our Nexus3 chuck as well as some other brands
- Work piece held in place by 8 rubber coated fixings
- Can be fitted in 7 different positions, in 12mm intervals, depending on the diameter required
- Jaws for the Nexus3 are compatible with the following chucks: Charnwood Nexus3 (Use existing Jaw Screws), Supernova (Requires our N3JS, 8 piece Jaw Screw Set), G3 Nova (Requires our N3JS, 8 piece Jaw Screw Set), Robert Sorby Patriot (Requires our N3JS, 8 piece Jaw Screw Set), Record Power SC3 (Requires our N3JS, 8 piece Jaw Screw Set), Record Power SC4 (Requires our N3JS, 8 piece Jaw Screw Set)
- Please note: All dimensions stated are when fitted to a Charnnwood Nexus3 chuck. When these jaws are fitted to a compatible chuck, the dimensions will change, depending upon the amount of jaw travel it has
Specifications
| Name | Charnwood (N3FJ10) Bowl Reversing Jaws 10" Diameter for Nexus3 Chuck |
|---|---|
| SKU | 5060281698582 |
| Brand | Charnwood |
| Diameter when closed | 210mm |
| Diameter when opened | 237mm |
| Minimum jaw travel required | 24mm |
| Bowl diameters | 45mm up to 217mm |
| Max. rpm | 600 |
In the box
- 8 x 10mm diameter x 17mm long rubber coated fixings
- 8 x 10mm diameter x 13mm long rubber coated fixings
