Charnwood (VIPER3R) 4 Jaw Geared Scroll Chuck - 95mm Diameter

Upgrade your workshop setup with the Charnwood VIPER3R 4 Jaw Geared Scroll Chuck, the best-selling 95mm diameter choice from the trusted Charnwood Viper range. Ideal for midi sized lathes and upwards, this high precision self centring chuck features a fully enclosed design that prevents the build up of chips and dust inside the gear mechanism. Engineered for simple one handed operation, its geared mechanism adjusts the jaws smoothly, while locking screws allow safe use on a lathe with reverse direction when your lathe conforms to DIN800 standard or Jet Type T38 design. Backed by a 1 year product guarantee with a trade rating, it is a versatile addition to any serious woodturner's kit.

The standard dovetail jaws grip your work piece both internally or externally depending on the style and shape of the piece to be turned. It fits directly onto lathes with headstock thread size M33x3.5tpi, with an optional insert required for all other sizes. For initial mounting of bowl blanks, Wigley DIY includes a wood screw which clamps into the centre of the chuck. Fully compatible with an extensive range of optional jaws and accessories, the Viper3R range jaws also work with Charnwood Viper3, Charnwood W836 (Requires V3JS), Vicmark VM100 (Requires V3JS), Vicmark VM90 (Requires V3JS), Record RP4000, Rutlands Dakota XT700, Warco 9405, Craft Supplies CS400, and Fox FX4000.

Features

• 4 Jaw Scroll Chuck with locking screws for using on a lathe with reverse direction
• Best selling size from the Charnwood Viper range
• 4 sized scroll chuck with jaws adjusted by a geared mechanism for simple one handed operation
• Self centring, high precision design ideal for Midi sized lathes and upwards
• Fully enclosed design prevents the build up of chips and dust inside the gear mechanism
• Standard dovetail jaws grip the work piece both internally or externally
• Fits directly onto lathes with headstock thread size M33x3.5tpi (optional insert required for other sizes)
• Includes a wood screw clamping into the centre of the chuck for initial mounting of bowl blanks
• Locking screws allow the chuck to be locked onto the lathe spindle (conforming to DIN800 standard or Jet Type T38 design, requires 3mm Hex key not included)
• Reverse direction should only be used when mounted directly onto an M33 x 3.5 spindle thread and not with a thread adapter
• Extensive range of optional jaws and accessories available

Specifications

In the box

• Standard dovetail jaws
• Rear cover plate
• Wood screw
• T-bar 8mm square drive for scrolling the jaws
• T-handled hex key 4mm for removing the jaws
